Marine Engine Parts

OUR PARTNERS

EMD Compatible

KOBELT

At Kobelt Manufacturing you can find rugged, robust control, steering and braking systems for managing and guiding movement on vessels, rigs, equipment and other machinery.

Marine Controls

The industry's widest range of electronic, push-pull & pneumatic vessel controls.

Steering Components

Complete steering systems & components for vessels of all makes & sizes.

Disc Brakes

Powerful disc brakes that slow, stop or control movement on equipment or vessels.

Accu-Steer Pumps

Accu-Steer autopilot pumps, steering manifolds & hydraulic power units.

Bow & Stern Thrusters

Rugged, easy to maintain hydraulic & electric bow & stern thrusters.

Digital Fin Stabilizers

Rugged and durable digital foil fin stabilizers that provide near natural buoyancy.

Get-Home Drives

Hydraulic auxiliary prop drive mounted in a vessels main drive line to turn a vessel's propeller.

Monitoring & Alarms

Vitals provides a complete vessel monitoring & alarm system to provide early warning of issues.

Hydraulic Solutions

Custom HPUs & other hydraulic solutions that complement Kobelt products & systems.

TDI Tech Development

T100-V (Pre-Engaged Starter) & T100-B (Inertial-Emgaged Starter)

TDI has pioneered the use of turbine techonogy with its unique twin turbine powered air starter for use on industrial, diesel, natural gas reciprocating engines, as well as a vatiety of industrial gas turbine engines

The Masson-Marine gearbox

All our gearboxes are symmetric with respect to the direction of rotation; the output shaft may run in engine-wise direction or in counter-engine-wise direction in the ahead mode of the ship.

Masson-Marine transmission names are composed as follows

First part of the name

MM : Masson-Marine
W : “workboat”, as our gearboxes are designed for professional applications in continuous operation
Number : this is the model type; the higher the number, the higher the power ratio that can be transmitted

Last part of the name

The gearbox is a standard gear with vertically offset input and output shaft lines.
NC : No Clutch
NR : “Non Reversing” – this transmission is a clutch/de-clutch gearbox (no reverse gear).
CEW : “counter-engine-wise” means that the direction of rotation of the output shaft is the opposite of the input shaft rotation.
EW : “engine-wise” means that the input and output shafts rotate in the same direction.
C : “coaxial”. The input and output shaft lie in line with one another.
DS : “dual speed” – this gearbox has two different reduction ratios

Example

MM W 20000 NR CEW: non-reversing transmission, model 20000, with input and output shafts rotating in opposite directions.

Learn How to Determine Transmission Names

Options And Special Features

Our gearboxes have a reliable and steady hydraulic system, and strong casings machined with high precision. They are suitable for continuous heavy-duty operation.

As an optional equipment, we can also supply the engine coupling, the propeller shaft coupling flange with registering coupling bolts, and SAE bell housings.

Kocsis Techologies

Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris.

Accumulators

Custom Accumulators

Piston Accumulators

Bladder Accumulators

Hydraulic Starters

Hydraulic Starters Series A (CMO)

Hidraulic Starters Series C (CMD-2A)

Hydraulic Starters Series B (CMA)

Hydraulic Starters Series D (CMD-3A)

Hydraulic Starters Series E (CME-5A)

Pumps

Hand Pumps

Recharging Pumps

Valves

Control Valves

Soft Engage Valve

Filters

High Pressure Filter

Low Pressure Filter

EMD Compatible Engine Parts

Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris.

One-Piece Liners

Our one-piece liner has an external water jacket integral to the liner, removing the possibility of water leaks, while water passages up to twice the size of those in OEM assemblies improve cooling. These structural improvements have resulted in customer-reported reductions in lube oil consumption of up to 20%. Liners are available as hardened, unhardened and chromed.

High-Strength Cylinder Heads

High-strength Class 50 iron alloy, hardened valve guides and the elimination of core plugs make our cylinder heads the most durable on the market, delivering maximum performance and cooling efficiency. Every head is tested for water integrity and clean passages and has an ultrasonic controlled fireface thickness.

Long-Life Pistons

Our pistons are alloyed cast iron for high strength, and our laser-hardened ring lands exhibit superior wear rates. For easy break-in, we coat pistons with tin or phosphate lube.

Durable Rods, Carriers & Pins

We use premium-quality steel and proprietary forging and hardening processes to produce long-lasting connecting rods, carriers and piston pins. Every rod is shot-peened for strength.

Premium-Quality Gears

Our gears for EMD engines are precision-ground, never shaven. Gears are manufactured to meet AGMA Class 10 standards. Gear components include new idler gear stub shafts, counterweights, gear harmonic dampers, accessory drive gears and related accessory drive components, as well as new and remanufactured turbo spring drive gears and 710 external clutches.

EMD - Blowers, Ducts & Manifolds Photo

Our roots blowers for EMD engines have all new critical earing and sealing components as well as improved oil pan gaskets. These features improve reliability and extend mean time between overhauls and overall component life. Heavy-duty construction, an improved design and protective surface treatment make our aftercooler ducts a reliable and durable replacement for OEM components. Fully compatible with the 645 engine, our ducts exhibit reduced potential for surface cracking and offer easy fit-up, avoiding turbocharger misalignment. Our exhaust manifolds feature an improved design for greater durability with chamber mounting holes that maximize ease of alignment and fit-up with the EMD 645 crankcase.

Wabtec Marine Parts & Services organization provides

World-wide Partner Network to support our marine and stationary installed base
Product Installation & Commissioning
Inventory of genuine OEM spare parts and OEM qualified refurbished spare parts with expert teams supporting 24/7/365 operations
World-class hands on Technical Training & Certification for our Regional Service Leaders, Partners and Customers
